PWM DC Motor Speed Controller, 30 Amp (MXA066)
Item Details
PWM DC Motor Speed Controller, 30 Amp (MXA066)
Item Name:
PWM DC Motor Speed Controller, 30 Amp (MXA066)
Item #:
MX066
Price/ea:
$26.99
$24.99 (3 to 9 units)
$24.49 (10 to 49 units)
$23.99 (50 to 99 Units)
$23.49 (75 - 99)
$22.99 (100 and more )

Product Image Gallery:



Description

The motor speed controller has a potentiometer that controls the pulse width modulation output and has a max. current load of 30 Amps. This circuit allows you to obtain low operational speeds for DC motors without sacrificing torque. Popular uses for this product are as a motor controller, hydrogen electrolysis, DC light dimmers, LED lighting dimmers, and heating control.



Includes:

  • LM324 Op-amp
  • 2 IRF1404 MOSFETs with heat sinks
  • Large spade connectors



Suggestions:

  • MX033-66 Frequency Adjuster kit to change the operational frequency





Product Specifications

Power supply

12/24 VDC (jumper provided)

Load voltage

12/24 VDC (30 Amps max.)

PCB dimensions

3.85” x 1.59” x 1.25”  (approx. 100mm x 40mm x 30mm)

Output

Pulse Width Modulation

Motor speed range

0-100% adjustable

Operational frequency

100 Hz



Disclaimer

Bakatronics LLC makes no claims or warranty as to the fitness or design of this product for the use in generating hydrogen, HHO gas or other applications. The purchaser is solely responsible for the design and application and assumes all risks. Bakatronics LLC shall not be liable for any damages to equipment or for any bodily harm. Our maximum liability is strictly limited to the purchase price of the MXA066 at the time of original sale. Bakatronics LLC also shall not be responsible for units damaged by improper hook up or overloading! It is the purchaser's responsibility to properly protect the unit from overloads. If Bakatronics LLC inspection determines a unit to be defective, Bakatronics LLC will repair, repair or refund the purchase price at our option. Bakatronics LLC reserve the right to refuse to sell units to anyone that in Bakatronics LLC opinion, is not using the unit properly. Final warranty lies with original manufacturer of the MXA066 module.

Item Options
Options
Knob for 1/4" shaft Pot (Add $1.69)
30 Amp DC Panel Meter with Shunt (Add $29.99)
Crimp Terminal for #10-12 Wire (Add $1.00)
Crimp Terminal for #10-12 Wire, Round (Add $1.00)
Metal Fan Guard for 60mm cooling fan (Add $1.99)
60mm (2.3") 12 Volt DC Cooling Fan (Add $7.99)
Item Price
Your Price:
$26.99
Quantity:


Pulse Width Modulation Control, Uses: Motor Control, DC
Dimmer,
Electrolysis, Heating control. 30 Amps Max @ 12  volts DC.
Fully
Assembled & Tested
Please Click "More Info" for additional information &
availablity
