BK-115 Triple Welder Kit
Item #:
BK-115
Price/ea:
$19.99
Assembly Options
Optional Items
Quantity:
Your Price:
$19.99
Details

Description

Triple Welder Kit with sequenced operation to create a great welding or contruction scene.

The BK-115 Trip Welder Kit has 3 separate welder flash super bright white LEDs that produce simulated welding flashes. The circuit is programmed to simulate a welding scene where multiple welder are working. The three LEDs will run at seemingly random times where sometimes one welder is working, sometmes two and sometimes all three are working. The welding time at which welder(s) are working will randomly change to give the effect of a real life work scene. A pause time can be selected to stop the welding action so that there is no one welding for a while.

Great for contruction or repair shop scenes. The welder LEDs can also be located far appart if desired to simulate multiple scenes accross the layout.

Kit requires assembly, but can be purchased assembled and tested as an option.



Features

  • Small Compact Circuit
  • MicroComputer IC controlled with Welding Program Installed
  • Simulated Welding in three locatations with Pausing
  • IC can be reprogrammed or changed to run additional programs
  • High Quality Circuit Board
  • Voltage Regulator include in circuit
  • IC Socket to easily change MicroComputer Chip
  • 12" Leads for LEDs and Power Input
  • Reverse Polarity Protected Circuit
  • Circuit is expandable as new options become available
  • Custom Programs can be added
  • White 3mm Super Bright LEDs included

Available options

  • Assembly by Bakatronics
  • 5mm White LEDs
  • Custom welding rates & Sequences
  • Other Color LEDs
  • 9 Volt Battery Clip
  • On Off Switch
  • HO & N Scale Welding Figures & Equipment



Product Specifications

Input Voltage

6-14V

LED

Three 3mm white super bright LEDs

PCB Dimensions

0.75” x 2” x 0.5"

Included with kit

  • Pre-Programmed MicroController IC,
  • Circuit Board, Components,
  • 12" LED and Power leads,
  • Assembly instructions



This kit requires soldering to assemble the kit. A 15-30 watt soldering iron is recommended.
